The semi-high roof cab is hydraulically locked and remounted
DZ1672440002 駕駛室液壓鎖止后懸置安裝圖（半高頂）
DZ1600440064 鎖緊機構總成 Locking mechanism assembly
DZ1672440202 半高頂駕駛室液壓鎖止分裝總成 Hydraulic locking assembly for semi-high roof cab
DZ1672440120 駕駛室固定橫梁總成（半高頂）Cab fixed crossbeam assembly (semi-high roof)
116100440072 托架總成 Bracket assembly
DZ1600440011 駕駛室固定橫梁 Fixed crossbeam of the cab
199000190034 壓板 Pressure plate
DZ1672440075 右托架總成 Right bracket assembly
DZ1600440070 固定座總成 Fixed seat assembly
DZ1600440065 柱塞缸 Plunger cylinder
Q40008 小墊圈 Gasket
Q150B0812 六角頭螺栓（鍍鋅）Hexagonal head bolts (galvanized)
DZ1600440012 推板 Push plate
Q2540610 十字槽沉頭螺釘 Cross-groove countersunk screw
Q150B0816 六角頭螺栓 Hexagonal head bolt
Q150B08100 六角頭螺栓 Hexagonal head bolt
Q40308 彈簧墊圈 Spring washer
Q340B08 1型六角螺母 Type 1 hexagonal nut
Q150B0855 六角頭螺栓 Hexagonal head bolt
Q340B08 1型六角螺母 Type 1 hexagonal nut
190003559482 卡套式三通管接頭 Ferrule type three-way pipe fitting
190003559516 管接頭用螺母 Nuts for pipe joints
190003559561 卡套 Card holder
190003559462 卡套式直通接頭體 Ferrule type straight-through joint body
DZ1600440023 輸油管 Oil pipeline
DZ1600440026 管卡 pipe clamp
DZ9112821005 高壓軟管（一）High-pressure Hose (I)
DZ1600440024 管卡 pipe clamp
Q4008 小墊圈 Gasket
Q150B0816 六角頭螺栓 Hexagonal head bolt
190003559516 管接頭用螺母 Nuts for pipe joints
190003559561 卡套 Card holder
Q151B1470 六角頭螺栓 Hexagonal head bolt
190003888458 自鎖螺母 Self-locking nut
Q150B14130 六角頭螺栓 Hexagonal head bolt
Q40214 大墊圈 Big gasket
116100440004 套筒 Sleeve
116100440005 套管 Drivepipe
DZ1600440002 減震器 Shock absorber
116100440006 套管 Sleeve
Q151B1490 六角頭螺栓 Hexagonal head bolt
DZ1600440292 減震器托架 Shock absorber bracket
Q151C1235 六角頭螺栓 Hexagonal head bolt
190003888468 自鎖螺母 Self-locking nut
AZ1692440001 繩索 Rope
116029440078 繩索固定卡 Rope fixing clamp
Q150B0620 六角頭螺栓 Hexagonal head bolt
Q40106 平墊圈 Flat washer
Q40306 彈簧墊圈 Spring washer
Q340B06 1型六角螺母 Type 1 hexagonal nut
DZ9100821001 輸油管再加工圖 Reprocessing diagram of oil pipelines
